Raybestos 8565 - Raybestos Specialty - Truck Coated Brake Rotor
$68699
5 day lead time
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
RAYBESTOS part description
Product Description
Raybestos Specialty - Truck Coated Brake Rotor
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 6.555 IN |
| Center Hole Diameter | 166.5 MM |
| Construction | Full Cast |
| 9565 | Conventional |
| Discard Thickness | 1.65 IN |
| Discard Thickness | 41.9 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 9.398 IN |
| Inside Diameter | 238.7 MM |
| Mounting Bolt Hole Circle Diameter | 7.86 IN |
| Mounting Bolt Hole Circle Diameter | 199.65 MM |
| Mounting Bolt Hole Diameter | 0.657 IN |
| Mounting Bolt Hole Diameter | 16.7 MM |
| Mounting Bolt Hole Quantity | 10 |
| Nominal Thickness | 1.772 IN |
| Nominal Thickness | 45 MM |
| Outside Diameter | 16.909 IN |
| Outside Diameter | 429.5 MM |
| Overall Height | 2.091 IN |
| Overall Height | 53.1 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 10 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
| Notes | Wabco PAN 22-1 |
Additional Information
| Country of Origin (Primary) | CN |
| UPC | 00887213336382 |
Part Interchanges
RAYBESTOS 8565 Cross Reference
We have 2 alternatives for the 8565 by RAYBESTOS:
