Name: Stemco 309-0973 Wheel Seal - Guardian HP Seal
SKU: 3090973
Price: 77.99 USD
Availability: InStock

STEMCO part description

Product Description

Wheel Seal - Guardian HP Seal

Application Summary

GMC F-120 1985 and Up

Product Attributes

Width	0.91 IN
Seal Type	C7
Bore Diameter	6 .310 IN
INNER BEARING CONE	594A
INNER BEARING CUP	592A
INSTALL HANDLE/BODY	555-0001
OUTER BEARING CONE	575
OUTER BEARING CUP	572
SHOULDER OUTER DIAMETER	4 .767 IN
SPINDLE SHOULDER OUTER DIAMETER	4 .767 IN
TOOL HEAD	555-5071
UNIVERSAL AXLE TOOL HEAD	555-5076
Bore Diameter	6.31
SHOULDER OUTER DIAMETER	4.767
SPINDLE SHOULDER OUTER DIAMETER	4.767

Additional Information

Harmonized Tariff Code (HTS)	4016931050
UPC	00703832130036
VMRS Code	018002028

Part Interchanges

STEMCO® is a recognized global leader in manufacturing and supplying a comprehensive line of high-performance systems and components to the commercial vehicle industry. Its wide range of products includes wheel-end components, such as fasteners, hubcaps, bearings, seals, and mileage counters, and brake parts, which include brake drums, brake pads, and adjusters. It also offers suspension products like spring pins, king pin kits, polyurethane suspensions, tie rod assemblies, and mount and blocking components. All these products are made to the highest quality and safety standards to ensure superior performance and maximum durability even when used in the harshest of conditions. STEMCO is ISO-9001:2015 certified.
