Name: Stemco 383-0236 Drive Axle Wheel Oil Seal - Discover
SKU: 3830236
Price: 45.49 USD
Availability: InStock

STEMCO part description

Product Description

Drive Axle Wheel Oil Seal - Discover

Application Summary

12,000#, 14,600# Meritor Front Transit

Product Attributes

Width	0.932 IN
Bore Diameter	4.84 IN
BEARING GUIDE	570-0020
FLEET HUB TOOL	551-5346
GASKET NUMBER	330-3009
HUB CAP WITH GASKET	340-4046
INNER BEARING CONE	HM212049X, X1
INNER BEARING CUP	553X
INSTALL HANDLE/BODY	551-0001
Notes	Ford 9000# axle. Code N (FD-900), with 15x3 or 15x3-1/2 wedge brakes,use 382-8027 set.GMC only (FE-900), prior to 1960, use 310-1036 and 320-2031 sets. Be sure steering adjustment stop bolt does not interfere with ring.
OUTER BEARING CONE	3782
OUTER BEARING CUP	3720
Seal Type	L1
SHOULDER OUTER DIAMETER	3 .500 IN
SPINDLE SHOULDER OUTER DIAMETER	3 .500 IN
Standard Set Equivalent	382-8036
SHOULDER OUTER DIAMETER	3.5
SPINDLE SHOULDER OUTER DIAMETER	3.5
STANDARD SET EQUIV.	382-8036

Additional Information

Harmonized Tariff Code (HTS)	4016931050
UPC	00703832178656
VMRS Code	018001025

Part Interchanges
