Name: Peterson Lighting 821C-7 LED BACK-UP LIG
SKU: 821c7
Price: 20.49 USD
Availability: InStock

PETERSON LIGHTING part description

821C-7/822C-7 LumenX® Oval LED Back-Up Light, PL3

Peterson Lighting LumenX® Oval LED Back-Up Light

The Peterson Lighting LumenX® oval LED back-up light is made to meet the highest quality and safety standards for superior performance. It functions by warning other road users that your truck is about to move backward.

Features & Benefits

A 7-diode grommet-mount clear light that’s built to last for years
Must be properly mounted, either horizontal, vertical, or any 360° position, to meet FMVSS 108 standards
With an industry-standard PL3 socket that’s integrated into the housing to form a single, rugged unit
Has a skirted weld joint for extra moisture protection
Operating range is 9 to 16 volts
Provides voltage protection and consistent light output over the entire voltage range with its regulated design
Does not require to be “Top” positioned to meet FMVSS 108 standards
Precisely engineered to offer a direct fit and function

Product Description

LED BACK-UP LIGHT, OVAL, GROMMET-MOUNT, 6.5"X2.25"

Features & Benefits

Oval Back-Up Light
PL3 socket integrated into housing.
Single light meets DOT requirements when properly mounted.
Meets DOT requirements in any horizontal / vertical / 360° position.
821 kit includes light, grommet and 421-49 plug.
822 kit includes light and 421-49 plug.
See matching stop / turn / tail light on page 5.
See matching turn signal light on page 15.

grommet - poly bag - 421-18 - std qty 12

Product Attributes

Bulb Technology	LED
Bulb/diode Count	7
California Prop65 Required	Y
Container Type	poly bag
Height	2.31 in
Length	6.5 in
Lens Color	clear
Light Color	white
Maximum Voltage	16 Volts
Minimum Voltage	9 Volts
Mounting Type	grommet
Multi-volt	N
Regulatory Compliance	DOT
Shape	oval
Submersible	Y
Termination	PL3
Voltage	12 Volts
Width	1.62 in

Additional Information

Warranty Special	LIMITED LIFETIME WARRANTY See full warranty terms: https://pmlights.com/warranty
Warranty Special UOM	TX
Country of Origin (Primary)	US
Harmonized Tariff Code (Schedule B)	8512204000
UPC	00044464993157
VMRS Code	034003142

Part Interchanges

PETERSON LIGHTING 821C-7 Cross Reference

We have 1 alternatives for the 821C-7 by PETERSON LIGHTING:

M821C-7
