Peterson Lighting 824R-7 - LED Stop/Turn/Tail, Round, Flange-Mount 4", red, poly bag
- Part Number
- 824R-7
- Manufacturer
- PETERSON LIGHTING
- Description
-
LED Stop/Turn/Tail, Round, Flange-Mount 4", red, poly bag
details
$10794
Package Price for 6 Units
@ $17.99 per unit
In stock
limited availability at this price!
. Learn more
PETERSON LIGHTING part description
824R-7/826R-7 4" Round LED Stop, Turn and Tail Lights
Peterson Lighting Piranha® 4" Round LED Stop, Turn & Tail Light
For enhanced trucking safety, equip your truck with a high-quality Peterson Lighting Piranha® 4" round LED stop, turn & tail light. This product effectively combines all three crucial functions—stop, turn, and tail— into one industry-standard light.
Features & Benefits
- A flange-mount 7-diode light with white diodes behind the red lens
- Comes with an industry-standard PL3 socket and flange that is integrated into the housing to form a single unit
- With locking tabs for added plug retention
- Product’s operating range is 9 to 16 volts and is made compatible with 431-491 connecting plug
- Does not have to be “Top” positioned to meet FMVSS 108 requirements
- Engineered to meet the needs of any stop tail turn lighting situation
Product Description
LED STOP/TURN/TAIL, ROUND, FLANGE-MOUNT 4"
Features & Benefits
- 4" Round Stop / Turn / Tail Light
- 824 kit includes light and 431-491 plug.
- 826 kit includes light, grommet and 431-491 plug.
- PL3 socket integrated into housing.
- See matching backup light on Peterson LED Catalog page 47.
- See matching turn signal light on Peterson LED Catalog page 14.
grommet - bulk pack - B426-18 - std qty 100
Product Attributes
| Bulb Technology | LED |
| Bulb/diode Count | 7 |
| California Prop65 Required | Y |
| Container Type | poly bag |
| Diameter | 5.5 IN |
| Height | 5.5 in |
| Integral Reflex | N |
| Length | 5.5 in |
| Lens Color | red |
| Light Color | red |
| Maximum Voltage | 16 Volts |
| Minimum Voltage | 9 Volts |
| Mounting Type | flange |
| Multi-volt | N |
| Regulatory Compliance | DOT |
| Shape | round |
| Submersible | Y |
| Termination | PL3 |
| Voltage | 12 Volts |
| Width | 1.49 in |
Additional Information
| Warranty Special | LIMITED LIFETIME WARRANTY See full warranty terms: https://pmlights.com/warranty |
| Warranty Special UOM | TX |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8512204000 |
| UPC | 00044464993478 |
| VMRS Code | 034002059 |
Part Interchanges
PETERSON LIGHTING 824R-7 Cross Reference
We have 1 alternatives for the 824R-7 by PETERSON LIGHTING:
Peterson Lighting® is a family-owned company that produces and distributes vehicle safety lighting systems mirrors, and other related safety products and accessories. It has been in the business for 75 years, and currently, it offers over 2,200 products designed for various applications, including tilt-bed and cargo vehicles and light- and medium-duty trailers. Peterson Lighting believes that full commitment to quality is its responsibility as a market leader. All its components are designed and manufactured only in its ISO 9001/QS-9000-certified facility in Grandview, MO. This facility is handled by knowledgeable and highly skilled specialists, who are as dedicated and passionate as the company when it comes to quality.
